BIGTREETECH Upgrade PITFT50 V2.0 Graphic Smart Display DSI Interface 5 inch LCD Touch Screen Suitable for Raspberry Pi

Enhance your Raspberry Pi experience with the BIGTREETECH Upgrade PITFT50 V2.0 Graphic Smart Display. This 5-inch LCD touch screen is designed to seamlessly integrate with your Raspberry Pi, providing a vibrant and interactive visual interface.

With a resolution of 800 x 480, this display delivers crisp and clear images, allowing you to fully immerse yourself in your projects. The display area measures 108 x 64.8mm, providing ample space for your creations to come to life.

The PI-TFT50 V2.0 is equipped with a capacitive touch panel that supports 5-point touch, allowing for precise and responsive interactions. Whether you’re navigating menus, playing games, or working on projects, you’ll have complete control at your fingertips.

Installing the display is a breeze thanks to the unique hole design on the back, which allows for direct installation of your Raspberry Pi. No external power supply is required as the display conveniently utilizes the Raspberry Pi’s power supply.

Adjusting the backlight brightness is easy with the hardware backlight adjustment feature. Simply rotate the potentiometer behind the screen to achieve your desired brightness level.

If you encounter any issues, rest assured knowing that our professional technical after-sales team is ready to assist you. We value your satisfaction and are committed to providing excellent customer support.

Upgrade your Raspberry Pi experience with the BIGTREETECH Upgrade PITFT50 V2.0 Graphic Smart Display. Explore endless possibilities and bring your projects to life with this high-quality and versatile LCD touch screen.

BIGTREETECH Upgrade PITFT50 V2.0 Graphic Smart Display DSI Interface 5 inch LCD Touch Screen Suitable for Raspberry Pi

• Working Voltage: 3.3V (provided by Raspberry Pi display interface)
• Maximum Working Current: 320mA
• Screen Current: 100mA
• Screen Resolution: 800 x 480
• Video Interface: Raspberry Pi DSI
• Touch Points: 5 points
• Viewing Angle: 60°/70°/70°/70°
• RGB888-16 Trillion True Color
• Refresh Rate: 60Hz
• Luminous Rate: 280 cd/m2
• Working Temperature: -20℃ to 70℃
• Dimensions: 121mm x 76mm
• Mounting Hole Size: M2.5
• Outer Mounting Hole Position: 113mm x 68mm
• Inner Mounting Hole Position: 58mm x 49mm
• Use Tutorial:
1. The first step is to insert the SD card with the Raspberry-Pi system into the Raspberry-Pi.
2. Connect the DISPLAY interface of the 5-inch touch screen to the DISPLAY interface on the Raspberry-Pi through the provided FPC cable.
3. After powering on the Raspberry-Pi, you can use the 5-inch touch screen.
• Product Details:
• Is Discontinued By Manufacturer: No
• Package Dimensions: 6.46 x 4.76 x 1.73 inches; 7.37 Ounces
• Item Model Number: Pi TFT50 V2.0（ST）
• Date First Available: August 7, 2020
• Manufacturer: BIGTREETECH
• ASIN: B08FDGRXGF
